Optimizing Compressed Air Systems: Air Receiver Selection Guide

Proper air receiver selection is essential for an efficient and stable compressed air system. YCZX highlights the key guidelines below.

1. Capacity Sizing
The receiver volume should correspond to 10%–20% of the compressor’s free air delivery (FAD), with 15% as the standard. Increase to 20% for high or fluctuating demand; reduce to 10% for stable, low-demand applications.

2. Location: After the Aftercooler
Install the receiver downstream of the aftercooler. This prevents oil and water accumulation, improves safety, cools the air, and increases efficiency for downstream equipment.

3. Placement Before Refrigerant Dryers
Mount the receiver upstream of refrigerant dryers. It acts as a buffer, cooling the air and removing bulk moisture and oil, which stabilizes airflow and reduces dryer load.

4. Filter Positioning
Install main line filters, especially coalescing filters, after the receiver. This allows the receiver to remove most liquids and particulates first, extending filter life and cutting maintenance costs.

Correct receiver selection and placement form the foundation of a reliable, energy‑saving compressed air system. YCZX supplies expert support and quality components to help you meet these requirements and achieve peak performance with lower total cost of ownership.

For further details, visit the YCZX knowledge base or consult our engineering team.
